1724480012
1724480012
Images are for reference only See Product Specifications

1724480012

Manufacturer：Molex
Description：CONN HEADER R/A 12POS 4.2MM
ANGFU #：11770866-1724480012

Datasheet

Add to favorites

Free Sample

Let’s communicate

Thank you for visiting our website. If you have any questions, please contact us and we will be happy to assist you. You can contact us via email, Skype, or by filling out the form below.

You can contact us via email, Skype, or by filling out the form below.

Request a quote

Part Number
Manufacturer
Quantity
$ Target Price
Email
Remark
TYPEDESCRIPTION

Select Attribute

CategoryHeaders, Male Pins
ManufactureMolex
Mini-Fit Jr 172448Series
12Number of Positions
Through Hole, Right AngleMounting Type
SolderTermination
HeaderConnector Type
Board Lock, Glow Wire CompliantFeatures
Board to Cable/WireStyle
Locking RampFastening Type
2Number of Rows
Male PinContact Type
BrassContact Material
AllNumber of Positions Loaded
UL94 V-2Material Flammability Rating
BlackInsulation Color
0.165" (4.20mm)Pitch - Mating
TinContact Finish - Mating
100.0µin (2.54µm)Contact Finish Thickness - Mating
TinContact Finish - Post
SquareContact Shape
0.378" (9.60mm)Insulation Height
Shrouded - 4 WallShrouding
Polyamide (PA), NylonInsulation Material
0.165" (4.20mm)Row Spacing - Mating
0.142" (3.60mm)Contact Length - Post

1724480012, From Manufacturer: Molex, CONN HEADER R/A 12POS 4.2MM, part of IntegratedConnectors, Interconnects, Rectangular Connectors, Headers, Male Pins,
