TYPE	DESCRIPTION	Select Attribute
Category	Headers, Male Pins
Manufacture	JST
EH	Series
2	Number of Positions
Through Hole, Right Angle	Mounting Type
-25°C ~ 85°C	Operating Temperature
Press-Fit, Solder	Termination
Header	Connector Type
Board to Cable/Wire	Style
Latch Lock	Fastening Type
1	Number of Rows
3A	Current Rating (Amps)
Male Pin	Contact Type
Brass	Contact Material
All	Number of Positions Loaded
UL94 V-0	Material Flammability Rating
Natural	Insulation Color
0.098" (2.50mm)	Pitch - Mating
Tin	Contact Finish - Mating
Tin	Contact Finish - Post
Square	Contact Shape
0.165" (4.20mm)	Insulation Height
Shrouded - 3 Wall	Shrouding
Polyamide (PA66), Nylon 6/6	Insulation Material
0.157" (4.00mm)	Contact Length - Mating
0.126" (3.20mm)	Contact Length - Post
250V	Voltage Rating
